MMTS - Series-Parallel Circuit Trainer Kit

$2,200.00

We accept purchase orders for our products and services. For a quote, please contact scott@sbctrainingllc.com.

MMTS – Series-Parallel Circuit Trainer Kit

Magnetic Mat Electrical Training System

The MMTS – Series-Parallel Circuit Trainer Kit is a comprehensive Magnetic Mat Electrical Training System built to teach foundational electrical concepts in a hands-on, visual way. Using real-world automotive-style nodes, students explore simple circuits, Ohm’s Law, and the relationship between series, parallel, and series-parallel circuits—all while developing diagnostic skills through intentional faults and live testing.

This kit is ideal for beginning students or those needing a refresher before advancing into ECU-based or computer-controlled circuit systems.

Key Features:

  • Foundational Learning: Build student confidence by exploring basic circuit theory before introducing complex electronics.

  • Visual, Hands-On Engagement: Students physically wire circuits using automotive-style components on magnetic mats—no soldering required.

  • Fault-Based Diagnostics: Nearly every node (excluding the fuse) can be set to a fault condition, allowing instructors to challenge students with realistic problems.
    These repeatable fault scenarios reinforce voltage drop testing, circuit analysis, and critical thinking in troubleshooting.

  • Flexible Curriculum Delivery: Canvas-based course content includes instructional videos, practice exercises, and auto-graded quizzes for streamlined classroom management.

  • Built for the Classroom: Durable storage and labeling make it easy to deploy, pack up, and transport—perfect for high school, college, or technical programs.

We accept purchase orders for our products and services. For a quote, please contact scott@sbctrainingllc.com.

MMTS – Series-Parallel Circuit Trainer Kit

Magnetic Mat Electrical Training System

The MMTS – Series-Parallel Circuit Trainer Kit is a comprehensive Magnetic Mat Electrical Training System built to teach foundational electrical concepts in a hands-on, visual way. Using real-world automotive-style nodes, students explore simple circuits, Ohm’s Law, and the relationship between series, parallel, and series-parallel circuits—all while developing diagnostic skills through intentional faults and live testing.

This kit is ideal for beginning students or those needing a refresher before advancing into ECU-based or computer-controlled circuit systems.

Key Features:

  • Foundational Learning: Build student confidence by exploring basic circuit theory before introducing complex electronics.

  • Visual, Hands-On Engagement: Students physically wire circuits using automotive-style components on magnetic mats—no soldering required.

  • Fault-Based Diagnostics: Nearly every node (excluding the fuse) can be set to a fault condition, allowing instructors to challenge students with realistic problems.
    These repeatable fault scenarios reinforce voltage drop testing, circuit analysis, and critical thinking in troubleshooting.

  • Flexible Curriculum Delivery: Canvas-based course content includes instructional videos, practice exercises, and auto-graded quizzes for streamlined classroom management.

  • Built for the Classroom: Durable storage and labeling make it easy to deploy, pack up, and transport—perfect for high school, college, or technical programs.

Within the Series Parallel Circuit Trainer you will receive the following components:

2 Magnetic Mats (Series Circuit and OHMs law, and Series Parallel Circuit)

2 Battery “nodes” (digital volt meter with display)

2 Steel base plates

6 wire “nodes”

1 Spice-LT “node”

1 Splice-RT “node”

12V power supply

2 19mm LEDs

2 12mm LEDs

2 Latching Switches

2 Splice “nodes”

1 12V Power Supply with magnetic base

8AA batteries

Spare “node” bases

Spare jumpers

Plyers

2mm Allen Key
